Type G2E140-AE77-97
Motor M2E068-BF
Weight 2.5 kg
Fan size 140 mm
Rotor surface Painted black
Impeller material Sheet steel, galvanized
Housing material Die-cast aluminum
Direction of rotation Clockwise, viewed toward rotor
Degree of protection IP44; installation- and position-dependent as per EN 60034-5
Insulation class "B"
Moisture (F) / Environmental (H)
protection class
H0+
Max. permitted ambient temp.
for motor (transport/storage)
+ 80 °C
Min. permitted ambient temp. for
motor (transport/storage)
- 40 °C
Installation position Shaft horizontal or rotor on bottom; rotor on top on request
Condensation drainage holes On rotor side
Mode S1
Motor bearing Ball bearing
Touch current according to IEC
60990 (measuring circuit Fig. 4,
TN system)
< 0.75 mA
Motor protection Thermal overload protector (TOP) internally connected
Protection class I (with customer connection of protective earth)
Conformity with standards EN 60335-1; CE
Approval CSA C22.2 No. 77; CCC; UL 2111
EBM G2E140-AE77-79 Fan
