| Technical Specifications for C200H-AD001 | |
| Brand: | OMRON |
| Model: | C200H-AD001 |
| Number of Inputs: | 4 inputs |
| Voltage Input Signal: | 1 to 5V or 0 to 10V |
| Current Input Signal: | 4 to 20 mA |
| Max. Input Signal: | Voltage Input: +/- 15 V, Current Input: +/- 30 mA |
| Input Impedance: | Voltage Input: 1 M? min., Current Input: 250 ? (rated value) |
| Resolution: | 1/4000 max (full scale) |
| Converted Data: | 12-bit binary (0000 to 0FA0) |
| Accuracy (25°C): | (+/-)0.5% |
| Accuracy (0° to 55°C): | (+/-)1% |
| Conversion Time: | 2.5 ms max/point |
| External Connections: | 19-pin terminal block (removable) |
| Dimensions: | 34.5 x 130 x 128 mm (W x H x D) |
Omron Analog Input Module C200H-AD001
