SPECIFICATION
Show similar products (1234)|
Manufacturer
|
SCHNEIDER ELECTRIC | |
|
Type of protection
|
power breaker | |
|
Current rating
|
16A | |
|
IP rating
|
IP40 | |
|
Operating temperature
|
-25...70°C | |
|
Short circuit breaking capacity
|
50kA | |
|
Range of overcurrent release settings
|
11.2...16A | |
|
Protected poles description
|
3d | |
|
Kind of protection
|
thermomagnetic | |
|
Max. operating voltage
|
690V AC |
Description
This ComPacT NSX100N is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 50kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 16A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100N is part of Schneider Electric EcoStruxure Power architecture.
